React Component Library Tutorial

A component library is a collection of logically group components so that one can explore, select components and helps in maintaining consistent design across projects. nag-rlib built usng following components.

1. create-react-library

2. Storybook

3. react-testing-library

4. How to Create a React Library

---

You can create a React Library using the create-react-library (https://github.com/transitive-bullshit/create-react-library) CLI which uses Rollup.js and create-react-app.

Rollup.js is a module bundler for JavaScript which compiles small pieces of code into something larger and more complex, such as a library.

Steps:

1.Install create-react-library globally

This package requires node >= 10.

npm install -g create-react-library

2.Create Library

Fire up the command prompt and use the below commandcd

npx create-react-library

Microsoft Windows [Version 10.0.19042.985]

(c) Microsoft Corporation. All rights reserved.

C:\Nag\myDrive\blog\React\NagLib>npx create-react-library npx: installed 150 in 21.621s ? Package Name nag-rlib ? Package Description Nag React Library ? Author's GitHub Handle nagvbt ? GitHub Repo Path nagvbt/nag-rlib ? License NAG VBT ? Package Manager yarn ? Template default

3. Install RollupJs and configure

a. Install Babel Preset

yarn add --dev @babel/preset-react

yarn add --dev @babel/preset-env

add .babelrc file with below contents

{
  "presets": ["@babel/env", "@babel/preset-react"]
}

b. Install Rollupjs

yarn add --dev rollup

yarn add --dev rollup-plugin-delete

yarn add --dev rollup-plugin-peer-deps-external

c. Install Rollupjs Plugins

yarn add rollup-plugin-commonjs

yarn add rollup-plugin-node-resolve

yarn add @rollup/plugin-json

yarn add --dev @rollup/plugin-babel

yarn add --dev rollup-plugin-scss

c. Add rollup.config.js

    import babel from '@rollup/plugin-babel';
    import external from 'rollup-plugin-peer-deps-external';
    import del from 'rollup-plugin-delete';
    import resolve from 'rollup-plugin-node-resolve';
    import commonjs from 'rollup-plugin-commonjs';
    import json from '@rollup/plugin-json';
    import pkg from './package.json';

    const extensions = ['.js', '.jsx'];

    export default {
      input: pkg.source,
      output: [
        { file: pkg.main, format: 'cjs' },
        { file: pkg.module, format: 'esm' }
      ],
      plugins: [
        resolve({
          extensions,
          modulesOnly: true
        }),
        json({
          compact: true
        }),
        commonjs(),
        external(),
        babel({
          exclude: 'node_modules/**'
        }),
        del({ targets: ['dist/*'] })
      ],
      external: Object.keys(pkg.peerDependencies || {})
    };

d. Update the commands

Add below commands in scripts section of package.json

"build": "rollup -c", "build:dev": "rollup -c -w",

3. Build and Launch the example site

---

To get started, in one tab, run:

$ cd nag-rlib && yarn build

And in another command window, run the create-react-app dev server:

$ cd nag-rlib\example && yarn start

4. Create Github Repo and push the code

---

Steps: Refer Code changes here

a. Open command prompt and Fire up the command

cd nag-rlib

Use the below Git Commands to set the email and user name of the github

1.Update email and username using:

a.git config user.email "[email protected]" b.git config user.name "nagvbt"

2.Check if they are updated correctly:

a.git config user.email b.git config user.name

b. Create a new repository in Github with the same project name say nag-rlib

Create a new repository
…or push an existing repository from the command line

git remote add origin https://github.com/nagvbt/nag-rlib.git git branch -M main git push -u origin main

5. Upgrade Packages

---

To upgrade the Packages to latest by using the command yarn upgrade --latest

Steps: Refer Code changes here

6. Export Multiple Components

---

Steps: Refer Code changes here

1. Create Two componentsa. src\ExampleComponent1\ExampleComponent1.jsx

import React from 'react';
import styles from '../../styles.module.css';

function ExampleComponent1({ text }) {
  return <div className={styles.test}>Example Component 1: {text}</div>;
}

export default ExampleComponent1;

b. src\ExampleComponent2\ExampleComponent2.jsx

import React from 'react';
import styles from '../../styles.module.css';

function ExampleComponent2({ text }) {
  return <div className={styles.test}>Example Component 2: {text}</div>;
}

export default ExampleComponent2;

2. Rename src\index.js to src\index.jsx
3. Change the extension of index.js to index.jsx in package.json"source": "src/index.jsx",
4. Import the ExampleComponent1 and ExampleComponent2 in index.jsx and export them so that the example component can consume the two components

    import ExampleComponent1 from './components/ExampleComponent1/ExampleComponent1';
    import ExampleComponent2 from './components/ExampleComponent2/ExampleComponent2';

    export { ExampleComponent1, ExampleComponent2 };

5. Install Storybook

---

Storybook makes development faster and easier by isolating components with business logic. Install Storybook using below command.

npx sb init

Addons

Install Addons.

By Default you will get two Addons
a. Essential addons Refer
b. addon-links

1. Add Aditional addons Refer Code

S#	Addon	Command	Description
1	a11y	yarn add @storybook/addon-a11y –dev	Test components for user accessibility in Storybook
2	storysource	yarn add @storybook/addon-storysource –dev	View the code of your stories within the Storybook UI

8. Unit Testing and Code Coverage

---

Refer Code

a. Add React Testing Library Refer

It is a very lightweight solution for testing React components. It provides light utility functions on top of react-dom and react-dom/test-utils, in a way that encourages better testing practices. To install react-testing-library use the below command.

yarn add --dev @testing-library/react

b. Add DOM Testing Library Refer

The DOM Testing Library is a very light-weight solution for testing DOM nodes. To install DOM Testing Library use the below command.

yarn add --dev @testing-library/dom

c. Add Jest-Dom Refer

The @testing-library/jest-dom library provides a set of custom jest matchers that you can use to extend jest. These will make your tests more declarative, clear to read and to maintain. To install Jest-Dom use the below command.

yarn add --dev @testing-library/jest-dom

d. Add user-event Refer

user-event tries to simulate the real events that would happen in the browser as the user interacts with it. For example userEvent.click(checkbox) would change the state of the checkbox. To install user-event use the below command.

yarn add --dev @testing-library/user-event

e. Add below code in package.json under scripts section to run the tests and generate the code coverage.

"test:dev": "react-scripts test --coverage --coverageDirectory='coverage' --env=jsdom --watchAll",

f. Install jest-fail-on-console Refer

Utility to make jest tests fail when console.error() or console.warn() are used. To install user-event use the below command.

yarn add --dev jest-fail-on-console

9. Eslint

---

Refer Code

a. Install airbnb
This package provides Airbnb’s .eslintrc as an extensible shared config. Refer

npx install-peerdeps --dev eslint-config-airbnb

b. Install prop-types

Runtime type checking for React props and similar objects. Refer

yarn add prop-types

c. Install eslint-plugin-react-hooks
This ESLint plugin enforces the Rules of Hooks.

yarn add --dev eslint-plugin-react-hooks

Then extend the recommended eslint config:

    {
      "extends": [
        // ...
        "plugin:react-hooks/recommended"
      ]
    }

d. Install eslint-plugin-testing-library
ESLint plugin to follow best practices and anticipate common mistakes when writing tests with Testing Library
Refer

yarn add --dev eslint-plugin-testing-library

e. Install eslint-plugin-jest-dom

ESLint plugin to follow best practices and anticipate common mistakes when writing tests with jest-dom.
Refer

yarn add --dev eslint-plugin-jest-dom

Then extend the recommended eslint config:

    {
      "extends": [
        // ...
        "plugin:jest-dom/recommended"
      ]
    }

f. Install eslint-config-react-app
This package includes the shareable ESLint configuration used by Create React App.

yarn add --dev eslint-config-react-app

Then extend the recommended eslint config:

    {
      "extends": [
        // ...
        "react-app"
      ]
    }

10. Publish the Library to npm

---

The command used to publish the lib as a public library you need to have a login in https://www.npmjs.com/

yarn publish --access=public

Following questions will be asked

yarn publish v1.22.4 [1/4] Bumping version... info Current version: 1.0.0 question New version: [2/4] Logging in... info npm username: nagvbt info npm email: [email protected] question npm password: success Logged in. [3/4] Publishing... $ run-s build yarn run v1.22.4 $ microbundle-crl --no-compress --format modern,cjs Build "nagRlib" to dist: 357 B: index.js.gz 297 B: index.js.br 286 B: index.modern.js.gz 234 B: index.modern.js.br Done in 3.78s. success Published. [4/4] Revoking token... success Revoked login token. Done in 24.67s.
